DS-E001D 2.2kgf · cm torque angle motor/steering motor/building block servo motor with bidirectional output and clutch gear protection function compatible with LEGO bricks
| Operating Voltage : | 6.0~9.0V DC |
| Standby Current: | ≤10 mA at 7.4.0V |
| No Load Current: | ≤150 mA at 7.4V |
| No Load Speed: | ≤0.20sec/60°at 7.4V |
| Stall Current: | 7.4V; ≤1.0 A (STD.) |
| Stall Torque: | 7.4V; ≥1.5 kgf.cm (REF.) |
| Rotating Direction: | CCW(500→2500μs) |
| Pulse Width Range: | 500~2500us |
| Neutral Position: | 1500us |
| Operating Travel Angle: | 270°±10° |
| Mechanical Limit Angle: | 360° |
| Operating Temperature Range: | -10℃~+50℃； ≤90%RH |
| Storage Temperature Range: | -20℃~+60℃； ≤90%RH |
| Weight: | 29.5 ± 0.5g |
| Case Material: | ABS |
| Gear Set Material: | POM |
| Motor Type: | Core Motor |
DSpower E001D 2KG PWM Clutch Building Block Servo, designed for seamless compatibility with LEGO Robotics. This servo is a versatile and powerful component suitable for various robotic applications. With a 2KG torque capacity, it provides robust performance and precise control for your LEGO robot projects.
Key Features:
High Torque Capacity: The servo offers a reliable 2KG torque capacity, ensuring it can handle a variety of tasks with ease.
PWM Control: Utilizing Pulse Width Modulation (PWM) control, it allows for accurate and customizable servo control, enabling smooth and precise movements.
Building Block Design: Designed as a building block servo, it seamlessly integrates into LEGO Robotics projects, allowing for easy incorporation into your creations.
Versatile Applications: Suitable for a wide range of applications, from simple movements to more complex robotic tasks, making it an essential component for LEGO robot enthusiasts.
Durable and Reliable: Crafted with durability in mind, this servo is built to withstand the demands of robotics projects, ensuring long-lasting and reliable performance.
Enhance the functionality of your LEGO robots with the 2KG PWM Clutch Building Block Servo, providing the torque and precision needed for your creative endeavors. Whether you are a beginner or an experienced robotics enthusiast, this servo is an excellent addition to your LEGO Robotics toolkit.
Application Scenarios
For Lego robot Lego toy..
FAQ
A: Yes, Through 10years research and development of servo, De Sheng technical team is professional and experienced to offer customized solution for OEM,ODM customer, which is one of our most competitive advantage.
If above online servos does not match your requirements, please do not hesitate to send message to us, we have hundreds of servos for optional, or customizing servos based on demands, it is our advantage!
A: DS-Power servo have wide application, Here are some of applications of our servos: RC model, education robot, desktop robot and service robot; Logistics system: shuttle car, sorting line, smart warehouse; Smart home: smart lock, switch controller; Safe-guard system: CCTV. Also agriculture, health care industry, military.
A: Normally, 10~50 business days, it depends on requirements, just some modification on standard servo or a totally new design item.
-
