Product

DS-B009-C 28kg High Torque Metal Gear All-Aluminum Casing Brushless Servo

Operating Voltage 6.0-8.4V
No Load Speed ≥0.14sec./60° at 6.0V, ≤0.12sec./60° at 7.4V
Rated Torque 6kgf.cm 6.0V, 7kgf.cm at 7.4V
Stall Current ≥7A at 6.0V, ≥8A at 7.4V
Stall Torque ≥28.0kgf.cm at 6.0V, ≥32.kgf.cm at 7.4V
Pulse Width Range 500~2500μs
Operating Travel Angle 180°+10°
Mechanical Limit Angle 210°
Weight 70g
Case Material Aluminium alloy Casing
Gear Set Material Metal Gears
Motor Type Brushless Motor

Product Detail

Product Tags

DSpower B009-C servo is an advanced and robust servo motor designed for applications that demand superior torque, durability, and precise control. With its high-torque output, metal gears, and all-aluminum casing, combined with the efficiency of brushless motor technology, this servo is engineered to excel in demanding tasks.

Waterproof Servo
incon

Key Features and Functions:

product_2

High Torque Output (28kg): This servo is built to deliver an impressive high torque output of 28 kilograms, making it well-suited for applications that require substantial force and precise control.

Metal Gear Design: Featuring metal gears, the servo ensures durability, strength, and the ability to handle heavy loads. Metal gears contribute to the longevity and reliability of the servo.

All-Aluminum Casing: The servo is housed in an all-aluminum casing, providing not only structural integrity but also effective heat dissipation. This robust construction ensures optimal performance under challenging conditions.

Brushless Motor Technology: The inclusion of brushless motor technology enhances efficiency, reduces wear and tear, and contributes to a longer service life compared to traditional brushed motors. It also aids in smoother and more precise control.

Precision Control: With a focus on precise position control, the servo enables accurate and repeatable movements. This precision is essential for applications where exact positioning is a critical requirement.

Wide Operating Voltage Range: The servo is designed to operate within a versatile voltage range, providing flexibility for integration into different power supply systems.

Plug-and-Play Compatibility: Engineered for seamless integration, the servo is often compatible with standard pulse-width modulation (PWM) control systems, enabling easy control via microcontrollers or remote devices.

incon

Application Scenarios

Robotics: Ideal for high-torque applications in robotics, the servo can be used in various robotic components, including robotic arms, grippers, and other mechanisms requiring powerful and precise control.

RC Vehicles: Well-suited for remote-controlled vehicles, such as cars, trucks, boats, and airplanes, where the combination of high torque, durable metal gears, and robust casing is crucial for optimum performance.

Aerospace Models: In model aircraft and aerospace projects, the servo's high torque output and durable construction contribute to precise control of control surfaces and other critical components.

Heavy-Duty Industrial Applications: Suited for heavy-duty industrial tasks, the servo can be integrated into machinery and equipment used in manufacturing, material handling, and other applications requiring robust and powerful movement.

Research and Development: In research and development environments, the servo is valuable for prototyping and testing, particularly in projects that demand high torque and precision.

Professional RC Racing: Enthusiasts engaged in professional remote-controlled racing benefit from the servo's high torque and responsiveness, enhancing the performance of racing vehicles.

Automation Systems: The servo can be utilized in various automation systems, including robotic assembly lines, conveyor controls, and other applications requiring efficient and precise movement.

DSpower B009-C represents a state-of-the-art solution for applications where strength, durability, and precise control are critical. Its advanced features make it well-suited for demanding industrial tasks as well as high-performance robotics and remote-controlled applications.

incon

FAQ

Q: What certifications do your servo has?

A: Our servo have FCC, CE, ROHS certification.

Q: Can I get a free sample?

A: Some servo support free sample, some do not support, please contact with us for more detailed information.

Q: What is the pulse width of servo?

A: It is 900~2100usec if no special requirement, please do contact with us if you need special pulse width.

Q: What is your servo's rotation angle?

A: The rotation angle can be adjusted according to  your  requirements, but it is 180° at default, please do contact with us if you need special rotation angle.
